IronStrike Montage Contemporary Pellet Stove — Specifications

IronStrike · Specifications · PDF, 566 KB

Specifications · PDF · 566 KB
Montage_Specifications.pdf
Download / view PDF ↓

About the IronStrike Montage Contemporary Pellet Stove

This stove meets 2016 EPA Regulations

The IronStrike Montage pellet stove is perfect for the contemporary home. With a variable flame height, you have complete control over the look of the fire. With 32,000 BTU's of efficient heat output, the Montage EPA pellet stove is sure to keep you warm.

The IronStrike Montage™ pellet stove is truly designed for modern times. Offering four distinct trim kits, the Montage pellet can be customized to fit nearly any decor. Because the large hopper and automatic feed system erases the need for steady fire maintenance, operating the stove is easy, unproblematic and economical. The Montage pellet stove effectively burns standard-grade fuel, saving expense while delivering dependable, low-maintenance heat. This stove is the ultimate in modern comfort— beauty, efficiency and above all performance.

Features

  • Reflective ceramic glass effectively radiates heat and blocks firebox view when not in use.
  • Wall mount thermostat precisely controls room temperature and provides fully automatic operation.
  • Effectively burns standard- and premium-grade fuel in fully automatic mode, offering a dependable, low-maintenance heat source.
  • Large 50 lb. hopper and automatic feed system eliminates constant tending to the fire and burnout.
  • Patented UltraGrate™ achieves nearly 100% combustion efficiency.
  • FastFire™ self-ignitor for one-button starting.
  • Ash drawer is easily accessible and can be removed quickly for simple cleaning.
  • 20 Year Warranty

Options

  • Four different trim kits are available: Arch, Artisan, Contemporary and Cast-iron Gothic Arch.
  • Can be vented horizontally through an outside wall.
  • A decorative log set can be added to complete the look.

Specifications

ModelIronStrike Montage Pellet Stove
BTU32,000
ControlsVariable Flame / Variable Blower
ThermostatStandard
Width23"
Height28-3/8"
Depth21-3/4"
WarrantyLimited Lifetime Warranty
Flue Size3" Rear Vent
Ship. Weight285 lb.
Ship. Volume22.06 cu. ft.
Floor Protection RequirementsFront & Sides: 6”(152 mm) Back: Up to 6”(152 mm)
Hopper Capacity 55 Lbs
Burn time15 - 37 hours
Fuse, Control Board Fuse, Igniter5 Amp, 250 volt, 3AGw 6 Amp, 125 volt
Efficiency82%
Convection (room air) Blower150 CFM; 1.5 Amps, 2175 rpm
Combustion Blower95 CFM: 1.0 Amps, 3000 rpm
Auger Motor Standard Features1.25 RPM; 0.48 Amps
