About the J.A. Roby Wood Stove - Discontinued*
*PRODUCT DISCONTINUED - This page is for informational purposes only.
With high effectiveness combustion and low clearances, the Mystere from J.A. Roby is a smart and stylish choice for anyone in the wood stove or cook stove market.
*PRODUCT DISCONTINUED - This page is for informational purposes only.
The Mystere offers a 20" x 12" viewing window and many stylish options to make fit your needs exactly, without having to sacrifice the even warmth and high combustion. EPA certified, the Mystere also offers an oven that can give you the opportunity to enjoy the traditional way of cooking on a wood fire.
Features
- Model without oven
- Two cast irons doors
- High efficiency combustion
- Convection and radiation heating system
- Air-wash system
- Low clearance to combustibles materials
- Easy access ashes drawer
- Can be used as an extra cooking stove
- Offered in one tone finish: metallic black, honey-glow brown or in rustic style finish: Metallic black hammered charcoal, metallic black hammered brown
Options
- Oven
- Blower thermodisc kit
- Rigid fire-screen
Specifications
| Specifications | J.A. Roby Mystere |
| Type of fuel | Wood |
| Recommended heating area | 500 - 1850 pi² / 46- 172 m² |
| Maximum output | 52000 BTU/h |
| Exteriors dimensions | |
| Width | 26" - 66.04 cm |
| Height | 31" - 78.74 cm |
| Depth | 27 ¾" - 70.49 cm |
| Type of chimney | 2100° F. - 650° C |
| Exaust pipe diameter | 6" - 15.24 cm |
| Recommended chimney diameter | 6" - 15.24 cm |
| Minimum chimney height | 12' - 3.66 m |
| Firebox dimensions | |
| Width | 18" - 45.72 cm |
| Height | 12" - 30.48 cm |
| Depth | 17 ¾" - 45.09 cm |
| Door opening dimensions | 17 ½" x 9 ½" 44.45 cm x 24.13 cm |
| Minimum clearances to combustibles | |
| Back | 8" - 20.32 cm |
| Side | 12" - 30.48 cm |
| Corner | 12" - 30.48 cm |
| Top (measured from floor) | 84" - 213.36 cm |
| Weight | 380 lbs / 172.36 kg |
| Warranty | Limited lifetime |
| Standard test - emissions | EPA |
| Standard test - safety | ULC-S627-00 |
Photos
