About the Astria Libra / Superior DRT4000 Multi-View Direct Vent Gas Fireplace

This fireplace meets all 2015 ANSI barrier requirements.

The Astria Libra / Superior DRT4000 Series gas-burning, direct-vent fireplace offers three multi-view configurations that serve as a primary focal point for any room. This Multi-View Vented Gas Fireplace Series offers several unique designs that create statements of style and substance in any home. Paradigms of beauty and value, these fireplaces are available in two-sided See Through, Corner* and three-sided Peninsula configurations.

The Astria Libra / Superior DRT4000 Series gas-burning, direct-vent fireplace offers three multi-view configurations that serving as a primary focal point to fit any decor. With an large glass viewing area and the intense flame presentation of a powerful pan burner, the Astria Libra / Superior DRT4000 Multi-View Series creates a beautiful, natural-looking fire that enhances the comfort and elegance of several rooms.


Features

  • Listed to ANSI Z21.88 Gas Fireplace Heater
  • Available in 40” clean-faced corner, peninsula & see through models
  • Combo top/rear flue configuration
  • Top flue configuration
  • Millivolt or energy saving electronic ignition
  • Pre-wired for wall switch
  • Outstanding heating efficiency for increased comfort and lower operating costs
  • Detailed ceramic fiber “aged oak” log set with 1/2" heavy-duty grate
  • Black painted interior (optional ceramic fiber liner available)
  • Durable textured powder coat finish
  • Uses IHP SV 4-1/2" x 7-1/2" Direct Vent Pipe
  • 20 Year Limited Warranty
  • This fireplace meets all 2015 ANSI barrier requirements.

Options

  • Optional blower and remote control available for all models




Specifications

ModelLibra/DRT40ST See Through / Libra/DRT40PF Peninsula
Venting TypeDirect Vent / Direct Vent
Framing Width48-1/2" / 43-5/8"
Framing Height47-3/4" / 47-3/4"
Framing Depth22-3/4" / 22-3/4"
BTU27,000 - 37,000 / 27,000 - 37,000
StyleTraditional / Traditional
View StyleSee Through / Peninsula
ControlsOptional Remote / Optional Remote
WarrantyLimited Lifetime Warranty / Limited Lifetime Warranty
ModelLibra/DRT40CR/L Corner
Venting TypeDirect Vent
Framing Width43-5/8"
Framing Height47-3/4"
Framing Depth24"
BTU22,000 - 31,000
StyleTraditional
View StyleCorner
ControlsOptional Remote
WarrantyLimited Lifetime Warranty
