DS Stoves 100-14 Kozy King Furnace

The Kozy King DS100-14 coal furnace is Amish made and is built for maximum efficiency and less fuel consumption. This coal furnace's efficiency is partly due to it being fully automatic with a secondary afterburn. The Kozy King is manufactured in the USA and is UL listed.

The DS100-14 Kozy King coal burning furnace by D.S. Machine Stoves is Amish designed and hand crafted to be clean burning and amazingly efficient - the 100-14 furnace has 85.1% efficiency! Hot water or hot air bimetal regulators are standard in all DS Machine Stoves and the DS100-14 also has the following features.

Features:

Burns Anthracite Coal only. (Note: Does not burn Bituminous Coal.)
Cast iron shaker grates
Cast Iron, airtight fire and ash door
Large loading door
Large ash pan
3-speed blower
3/16” plate steel
Fully automatic
Wall thermostat controlled
Fan and limit safety controls
Cast iron baffle
Special tubes through fire box for maximum heat circulation
Removable oxygen afterburner
Forced draft
Insulated cabinet
80/20 combustion bypass
Filter box left or right intake (18” x 18”)

Options:

Domestic water coil

Specifications	DS Stoves Kozy King DS100-14 Furnace
Fuel	Anthracite Coal
Fire box size	14" X 20"
Fire Chamber Volume	3.5 cu. ft.
Weight	700 lbs
Width	27.5”
Height	47.75”
Depth	27”
Depth including filter box	47”
Flue size*	6”
Warranty firebox	5 years
Height to center of flue	42.5”
Ash door size	5.5” X 16.5”
Load door size	12” X 11”
Heating sq. ft.	Up to 2,000 sq. ft.
BTU rating	90,000
Blower capacity, 3-speed	1100, 1650, 1350 cfm
Blower Static Pressure Low	-1.47 psig
Blower Static Pressure High	-1.42 psig
Plenum outlet size	18” X 18”
Efficiency	85.1%
Clearance from combustibles
Side and rear	18”
Front	48”
Top of plenum to ceiling	2”
Flue to wall	18”
