Margin Flame View Stove - Discontinued
Margin · 0 documents
We do not have documents on file for this model. Call us — we may be able to find one.
About
This product is no longer available through Obadiah's. This page is provided for information purposes.
- Heats approximately 1,500 Sq. Ft.
- Available in black, white, or almond porcelain finish
- Glass firebox door to view the fire
- Easy ash removal
- Finger-tip damper controls
- Beautifully finished porcelain oven
- Water reservoir - side built-on model or rear model attachment
- This stove is constructed with sheet metal panels that are bolted together
Flame View wood burning cook stove is manufactured in Canada by Margin Stoves and has been in business since 1975. It is one of the few cookstoves that offers a glass door on the firebox for a nice view of the fire. The Flame View is also one of the few cookstoves on which you can decide what side you would like the firebox on (comes standard on the left side). With an optional cast iron cooktop (for stoves with left side fireboxes only) this stove is sure to sastisfy your cooking needs. The Flame View offers many options not found in other cook stoves.
Flame View Features:
- Heating capacity of 1,500 square feet or more
- Airtight, bell draft controlled firebox will take up to a 17 inch log for an all night burn
- Takes standard firebrick that is inexpensive and easy to replace and install
- Steel cook top for a strong and evenly heated cooking surface
- Cast iron wood grate system
- Exclusive "Air Jet" re-burn design
- Large ash trays below grates for convenient ash removal
- Porcelain exterior finish throughout, standard in black
- Porcelain black oven interior
- Nickel plate trim or black trim are standard
- Ships with free poker, lid lifter and ash scraper
- First section of oval pipe is included
- Limited one-year warranty
Specifications
| Flame View Dimensions | Without Reservoir / With Reservoir |
| Overall size | 30" D x 46" W x 64"H / 30" D x 56" W x 64" H |
| Overall height to cooktop | 34 1/2" / 34 1/2" |
| Cooking surface | 25" x 40" / 25" x 40" |
| Back | 37" W x 21" H / 45" W x 23" H |
| Oven | 20" W x 13" H x 20" D / 20" W x 13" H x 20" D |
| Firebox | 22" L x 12" W x 18" D / 22" L x 12" W x 18" D |
| Log Length | 22" / 22" |
| Approx. burn time | 8 to 14 hours / 8 to 14 hours |
| Approx. heating area | 2,000 sq. ft / 2,000 sq. ft |
| Reservoir capacity | 20 gallons rear or 5 gallons on the side / 20 gallons rear or 5 gallons on the side |
| Flue outlet size | 7" / 7" |
| Shipping weight | 650 lbs. / 700 lbs. |
| UL Listing | 1482 / 1482 |
| Flame View Clearances to Combustibles | |
| Back wall to unit | 14" / 14" |
| Side wall to unit | 14" / 14" |
| Fuel door to side wall | 48" / 48" |
| Back wall to pipe | 15" / 15" |
| Side wall to pipe | 32" / 15" |
| Oven door to front | 48" / 48" |
| Chimney Connector | |
| Unprotected Surface | 18" / 18" |
| Protected Surface | 6" / 6" |
This model is no longer sold new. Its manuals stay here, and we still supply parts.
