Regency Cascades i1500 Hybrid Wood Fireplace Insert
Regency · 2 documents
PDF
Dimensions
Regency-Cascades-i1500S-Wood-Insert-Dimensions.pdf · 429 KB
PDF
Manual
Regency-Cascades-i1500S-Wood-Insert-Manual.pdf · 3.5 MB
About
This product is no longer available through Obadiah's. This page is for informational purposes only.
The Regency Cascades i1500 Hybrid Wood Fireplace Insert, featuring Eco-Boost triple burn technology, is perfect for sealing a drafty fireplace that isn’t quite big enough for a standard sized insert or where a more compact style heater is required. This catalytic insert offers an increase in efficiency, burn-times, and most importantly dramatically reduces emissions to an astonishing 1.0 gram/hour.
The Regency Cascades i1500 is backed by a limited lifetime warranty on both the stove and catalytic combustor.
Features
- The Cascades i1500 heat up to 1,200 square feet!
- Produces 55,000 BTUs
- Large fire viewing area, with heat radiating ceramic glass
- Wood-finished handle
- Heavy duty cast hinges
- Solid forged steel adjustable cam lock ensures a tight door seal over time
- Front mounted air adjustment & catalytic bypass
- Digital catalytic temperature monitor helps your stove reach maximum burn times & efficiency
- High performance brick-lined firebox reflects heat
- Non-obtrusive air wash system keeps glass clean
- Heavy gauge steel log retainers to stop logs from rolling
- Welded ash lip
- Triple-burn technology creates longer and more complete burns
- Limited Lifetime Warranty
Specifications
| Specifications | Regency Cascades i1500 Hybrid Wood Fireplace Insert |
| Fuel Type | Wood |
| Heating Area | Up to 1,200 sq. ft. |
| Firebox Volume | 1.3 cu. ft. |
| Max Burn Time | 10 hr. |
| Max Heat Output | 55,000 BTU/h |
| Optimum Efficiency | 84% |
| Average Particulate Emissions | 1.0 g/h |
| Max Log Length | 18" |
| Flue Outlet Diameter | 6" |
| Min Chimney Height | 15' |
| Overall Dimensions ( H x W x D) | 19-1/2"H x 22-3/4"W x 19-3/4"D |
| Minimum Fireplace Opening | 19"H x 23"W x 13-3/4"D |
| Viewing Area | 126 sq. in. |
| USA standard (Emissions) | EPA 2020 |
| Warranty | Limited Lifetime |
