SP24 The Blazer Breckwell Pellet Insert
Breckwell · 2 documents
PDF
Manual
Breckwell-SP24I-Pellet-Insert-Manual-2020.pdf · 5.2 MB
PDF
Warranty
Breckwell-Warranty-Policy.pdf · 383 KB
About
Decades of dedication to quality, reliability, value, and ease of operation are exemplified by The Blazer. Big heat, rich tradition.Available as either a free standing Model or an insert.
Available as either a free standing Model or an insert.
Available as either a free standing Model or an insert.
The The SP24I offers a large, convenient ash pan. Includes the "Hot Rod" automatic firestarter, and low 0.32 grams of particulate emissions.
SP24I Blazer Features:
- Up to 50,000 BTUs: Providing comforting heat from 400 sq. ft. to up to 2200 sq. ft. 5 heat settings.
- The automatic fuel feed lets you burn up to 70 hours on each load with the 70 lb. hopper fuel capacity.
- Heavy steel construction provides long-term reliability and durability.
- One touch digital technology control board with multiple safety checks and diagnostics; extends the life and efficiency of your stove.
- The “Hot Rod” Automatic Fire Starter igniter ensures the stove lights quickly and safely. No messy starter gels needed.
- Stainless steel burn pot. Removable for easy cleaning.
- Special air wash system helps keep glass clean.
- Up to 70 hours burn time
Specifications
| Specifications | SP24I |
| Flue Outlet | 3" or 4" |
| Shipping Weight | 210 lbs |
| Burning Time | Up to 70 hrs |
| Max BTU Input | 50,000 |
| Max sq. ft. range | 800-2,200 |
| EPA Status | Exempt |
| Hopper Capacity | Up to 70 lbs |
| Approved Installation | Masonry, Zero-clearance, Mobile Home Z-C, Built-in |
| Dimensions | / |
| Height | 21" (in fireplace) |
| Width | 22" (at rear) 29.5" (at opening) |
| Depth | 23.5" (total) 16.375" (in fireplace) |
| Flashing for Inserts (Large/Medium) | 48.5" x 32" / 44.5" x 28" |
| Clearances | / |
| Front (Hearth) | 6" |
| Side Wall | 5" |
| Mantel (from Stove) | 14" |
