IronStrike Striker C160 Fireplace Insert

IronStrike · 3 documents

About

The IronStrike Stiker C160 is a Compact, EPA Phase II-certified wood insert,  known to be one of cleanest burning non-catalytic models on the market, customizable for the ideal look.



EPA 2020 Approved!

The Striker™ C160 provides a popular and efficient alternative for a small masonry or factory-built fireplace and has been EPA 2020 approved. The Striker has been specially engineered to fit into almost any factory-built fireplace, enabling you to use your hearth as a whole-house heat source. Elegant extras for the Striker such as etched glass, plated trim, and variable-speed blowers allow you to create an insert that's perfect for your home.

IronStrike COUNTRY™ COLLECTION

  • Each Country Collection wood stove is EPA Phase ll & Phase III –certified and built with an advanced non-catalytic combustion system that not only burns the wood, but also the smoke, providing clean emissions, a clear large Ceramic Glass viewing window, and extra heat. Premium-grade steel materials, quality craftsmanship, and sophisticated technology ensure a lifetime of warmth guaranteed with a limited lifetime warranty!

Features

  • Unique air wash system keeps the glass clean and clear for a wide-open view of the fire
  • Constructed from premium materials, like heavy-gauge stainless steel, for dependable performance and striking appearance
  • Ceramic-fiber blanket utilizes technology developed by NASA that has 10 times the insulation value of firebrick, radiating heat back into the firebox and creating higher efficiencies and cleaner gas

  • Uniquely designed refractory baffle assists in igniting fuel-rich gases, increasing efficiency and reducing emissions
  • Stainless steel afterburner tubes mix oxygen with unburned gases and smoke to create a secondary burn, lowering fuel costs
  • Heavy-duty door contains no nuts or washers, forming a 360° seal for long-lasting durability
  • EPA Phase II-certified for clean and efficient operation
  • Singular draft control for simple operation and burn rate adjustment

Options

  • Two distinct door styles, five unique door finishes, and a choice of glass styling options for a customized look
  • Surround size and trim selections to fit your style and home


Required Accessories

Surround Panels 26 1/2" X 40"

  • Top Surround (71038)
  • Side Surrounds (71035)


Surround Panels 26 1/2" X 48"

  • Top Surround (71039)
  • Side Surrounds (71036)


Surround Panels 30 1/2" X 40"

  • Top Surround (71040)
  • Side Surrounds (71035)


Surround Panels 30 1/2" X 48"

  • Top Surround (71041)
  • Side Surrounds (71036)



Optional Accessories:


Surround Trim


  • Black 26 3/4" X 40" (71021)
  • Black 26 3/4" X 48" (71022)
  • Black 30 3/4" X 40" (71025)
  • Black 30 3/4" X 48" (71026)
  • Nickel 26 3/4" X 40" (71074)
  • Nickel 26 3/4" X 48" (71075)
  • Nickel 30 3/4" X 40" (71078)
  • Nickel 30 3/4" X 48" (71079)


Arch Faceplates


  • Nickel Arch Faceplate (71062)
  • Nickel Brushed Arch Faceplate (71144)


Traditional Faceplates


  • Traditional Brushed Nickel (71145)
  • Traditional Nickel (71059)

Blowers


  • Blower Black (H7907)
  • Blower Brushed Nickel (H7909)
  • Blower Nickel (H7910)

Offset Box


  • 8" Flue / 6" Exhaust, 0"-6" (H6832)
  • 8" Flue / 6" Exhaust, 6" - 12" (H6833)




Specifications

SpecificationsIronStrike Striker C160 Wood Insert
Minimum Fireplace Opening25-1/2"W x 19-1/2" x 12-3/4"
FuelWood
Venting6" Pipe
View StyleFront View
Heating Capacity*600-1,300 sq. ft.
BTU55,600 BTU/Hr
Max Log Length18"
EPAEPA Certified
Emissions1.6 g/hr
Weight320 lbs.
WarrantyLimited Lifetime
This model is no longer sold new. Its manuals stay here, and we still supply parts.
