About the DS Stoves 200-10 Ecomiser Furnace

The Ecomiser DS200-10 coal burning furnace is Amish made and is built for maximum efficiency and less fuel consumption. This coal furnace's efficiency is partly due to it being equipped with a manual draft and a secondary reburn. The DS200-10 is manufactured in the USA and is UL listed.

The DS200-10 Ecomiser furnace by D.S. Machine Stoves is Amish designed and hand crafted to be clean burning and efficient - the 200-10 furnace has 76.4% efficiency. Hot water or hot air bimetal regulators are standard in all DS Machine Stoves and the Ecomiser also has the following features.

Features:

Burns Anthracite Coal only. (Note: Does not burn Bituminous Coal.)
Cast iron shaker grates
Air tight cast iron fire and as door
Large loading door

Large ash pan
3/16” plate steel
Auto on and off blower
Removable oxygen reburn system

Options:

18” x 18” filter
Box with left or right inlet

Specifications

Specifications	DS Stoves 200-10 Ecomiser Furnace
Width	24”
Height	49.75”
Depth	29.5”
Fuel	Anthracite Coal
Heating Area	Up to 2,500 sq. ft.
Heating Output	120,000 BTU's
Efficiency	76.4 %
Firebox Dimensions	16" x 24"
Firebox Door Dimensions	14” x 14.5”
Fire Chamber Volume	5.5 cu. ft.
Log Length	22"
Ash Door Dimensions	16.5” x 5.5"
Plenum Outlet	18” x 18”
Depth (including filter box)	50.5”
Height to center of flue	44”
Flue	6”
Weight	500 lbs
Blower capacity	965 cfm
Clearances
Side	18”
Rear	24"
Front	48”
Flue/Stove Pipe	18”
Top of plenum to ceiling	2”
