Osburn 2000 Wood Stove — Manual

Osburn · Manual · PDF, 5.8 MB

Manual · PDF · 5.8 MB
Osburn-2000-Manual.pdf
Download / view PDF ↓

About the Osburn 2000 Wood Stove

The Osburn 2000 Stove proves it's worth as one of the most popular stoves in the Osburn range and has held that position for years. Revamped in 2018 to refine the design, setting new standards for emissions, the new version maintains the 2.4 cubic ft. firebox and offers up to 75,000 BTU/hr, while investing in an impressive emissions performance of about 1.54 g/hr! Designed to heat between 500 - 2,100 sq. ft. and burn up to 8 hours, this magnificent stove has an optimal efficiency rate of 77%

*Revised 7/20/20

With it's new cast iron door, it provides a youthful appearance with elegant lines while ensuring the spirit of wood heating remains. Not only is this stove impressive for it's technological advances but is customizable to your exact needs. Choose from refined door overlays, glass ash lip with an integrated ash pan, and new leg designs, make this stove your own.



Features:

  • The Osburn 2000 Wood Stove heat up to 2,100 square feet!
  • 75,000 BTU/hr heat output
  • High-efficiency appliance EPA approved
  • Emissions (grams/hour): 1.54 g/h
  • Optimum efficiency: 77%
  • Color: Metallic Black with optional door finishes
  • Firebox lined with refractory bricks
  • Stainless-Steel secondary-air system
  • Easy-to-access Ash Drawer
  • 2.4 cubic foot firebox
  • Log length up to 20"
  • Adjustable handle
  • Self-cleaning glass air-wash system
  • Ultra-quiet 120 CFM crossflow blower with variable speed control included
  • Mobile Home Approved

Specifications

Specifications: 2000 Osburn Wood Stove
Type of fuel Wood
Recommended surface 500 to 2,100 sq.ft.
Maximum output 75,000 BTU/hr
Overall Dimensions33-1/8"H x 27"W x 29"D
Exhaust pipe diameter 6"
Minimum chimney height 12'
Firebox Dimensions 11-7/8"H x 21"W x 16-3/4"D
Log positioning Over width
Maximum log length 20"
Width16.5"
Weight 390 lb
Efficiency77%
Emissions (grams/hour)1.54 g/h
Door opening dimensions (W.H.)17-1/2"W x 9"H
Glass surface 17-1/8"W x 10-1/4"H
Emission StandardEPA 2020
Warranty Limited lifetime
Mobile Home ApprovedYes
Minimum Clearance to Combustibles
Single-Walled PipeDouble Walled Pipe
Back 11" Back 6"
Sides 16" Sides 16"
Corners 10" Corners 7"
Top 84" Top 84"

Photos
