Osburn 900 Osburn Wood Stove - Discontinued — Manual
Osburn · Manual · PDF, 4.2 MB
About the 900 Osburn Wood Stove - Discontinued
The 900 model is designed to heat between 250 - 1,000 sq. ft thanks to a firebox of 1.3 cu. ft. and a burn time of up to 5hrs and an efficiency of up to 78%, this stove is sure to impress!
The 900 model is the smallest in the Osburn Woodstoves lineup. However don't let it's size fool you into thinking it is any less impressive, Osburn has ensured that this stove still incorporates the features and technology of the larger models.
This EPA stove packs a punch producing an output of up to 40,000 BTU/hr. with the ability to burn logs up to 17" in length.This small stove is an admirable stove in the small stove market. Designed to heat between 250 - 1,000 sq. ft thanks to a firebox of 1.3 cu. ft. and a burn time of up to 5hrs and an efficiency of up to 78%, this stove is sure to impress!
Features:- Heating capacity up to 40,000 BTU
- 1.3 cubic foot firebox
- Adjustable door handle
- Log loading over width
- Air-wash system
- Heavy-duty cast iron door
- Flue pipe diameter: 6"
- Log length up to 17"
- Weight of 174 lbs (79kg)
Options:
- Ultra-quiet crossflow blower with variable speed control
- Blower thermodisc kit ("on/off")
- Quick connect thermodisc kit
- Optimum efficiency: 82%
Specifications
| Specifications 900 Osburn | |
| Recommended Surface | 250 to 1,000 sq. ft. |
| Maximum output - EPA test wood | 26,100 BTU/hr |
| Maximum output - seasoned cord wood | 40,000 BTU/hr |
| Color | Metallic Black |
| Exterior Dimensions (W.H.D.) | 22 7/8" x 25 3/4" x 21 7/8" |
| Exhaust pipe diameter | 6' |
| Type of chimney | 2,100 deg. F (1150 deg. C) |
| Recommended chimney diameter | 6" |
| Minimum chimney height | 12" |
| Firebox dimensions (W.H.D.) | 18"x 12 1/2"x 9 1/4" |
| Log positioning | Over Width |
| Maximum log length | 17" |
| Door opening dimensions (W.H.) | 15'x 7 3/4" |
| Type of door | Glass with cast iron frame |
| Glass Surface | 103 sq. in. |
| Warranty | Limited Lifetime |
| Test standard- Safety | ULC S-627/UL 1482 |
| Test Standard- Emissions | EPA method 28 |
| Minimum clearances to combustibles | |
| USA | |
| Single walled pipe / Double walled pipe | |
| Back | 15 1/2" / 15 1/2" |
| Sides | 18" / 18" |
| Corners | 10" / 10" |
| Minimum clearances to combustibles | |
| Canada | |
| Single walled pipe / Double walled pipe | |
| Back | 15 1/2" / 15 1/2" |
| Sides | 18" / 18" |
| Corners | 10" / 10" |
Photos




Need help with this?
We have sold and serviced these appliances since 1999. If you need a part or advice, call us.
