About the Osburn 1700 Wood Burning Stove
Intended to address the issues of smaller spaces, the Osburn 1700 is a devoted duplicate of the recently reclassified 2000 model. This firebox joins strength and style to enable you to make the most of your warming experience with certainty. This unit is outfitted with high-thickness bricks, a cast iron entryway, built in ash pan, a top heat deflector that redirects warmth to the front of the unit, and side boards to lessen its clearances.
*Revised 7/20/20
Pick your preferred form by modifying the unit to suit your style: refined entryway overlays, new leg structures, glass ash lip; huge developments for the most prepared specialists. Regarding the most stringent enactment on molecule discharges with just 1.26 g/h, this wood stove is ideal for those hoping to go further.
Features:
- The 1700 Model heats up to 1,800 sq. ft!
- Secondary-air system- to improve gas combustion
- Refractory lined bricks - for better heat distribution
- Glass Air wash System
- Adjustable threaded legs
- Limited Lifetime Warranty
- UL listed
- EPA Certified
- 6 hr burn time
- 1.9 cu. ft. firebox volume
- 144 CFM Blower included equipped with an automatic heat sensor
Options:
|
130 CFM Blower w/ Variable Speed |
5" Fresh Air intake kit for wood stove on legs |
|
5" Fresh Air intake kit for wood stove on pedestal |
Glass Ash lip |
|
Rigid Firescreen |
Heat powered stove fan (105 CFM) |
Specifications
| Model 1700 Wood Burning Stove | |
| Fuel Type | Wood |
| Heating Area | 500 - 1,800 sq ft. |
| Firebox Volume | 1.9 cu. ft. |
| Max Burn Time | 6 hrs. |
| Max Heat Output | 65,000 BTU/hr |
| Optimum Efficiency | 78% |
| Average Particulate Emissions Rate | 1.26 g/hr. |
| Max Log Length | 18" |
| Flue Outlet Diameter | 6" |
| Minimum Chimney Height | 15 ft. |
| Glass Surface ( W x H) | 15-3/4" x 9-3/8" |
| Overall Dimensions ( H x W x D) | 30-3/8" x 24-7/8" x 23-1/4" |
| Door Opening Dimensions ( H x W) | 8-3/4" x 17-1/4" |
| Firebox Dimensions ( H x W x D) | 11-7/8" x 19-5/8" x 13-1/2" |
| USA Standards (Emissions) | EPA 2020 |
| Warranty | Limited Lifetime |
| Clearance to Combustibles | |
| Back Wall (Single Wall Pipe / Double Wall Pipe) | 14-1/2" / 6" |
| Corner Placement | 12" |
| Side Wall | 10" |
| Top - Measured from Platform the appliance is installed | 84" |
| Minimum Floor Protection in front | 18" |
Photos
