Osburn 3500 Wood Burning Stove — Manual

Osburn · Manual · PDF, 5.6 MB

Manual · PDF · 5.6 MB

Osburn-3500-Wood-Stove-Manual.pdf

About the Osburn 3500 Wood Burning Stove

Specifically intended to confront the thoroughness of winter, the Osburn 3500 Wood Stove is a basic for any spacious home, particularly in the event that you live in an area with brutal climate conditions. Regardless of its low emissions outflow of 1.32 g/h, this wood stove proposes an easy to use, non-catalytic innovation as well as a noteworthy decrease in fuel utilization.

*Revised 7/29/20

Features:

The Model 3500 Woodstove heats up to 2,700 square feet!
77% Efficiency
10 hr burn time
3.5 cu. ft. Firebox volume
EPA Certified
Approved for Mobile Home and Alcove Installation
Glass Airwash System
Refractory brick-lined firebox - for better heat distribution
Secondary-air system - to improve gas combustion
UL Listed
Limited Lifetime Warranty

Options:

Rigid Firescreen

Glass Ash Lip

5" Fresh Air Intake Kit

Specifications

Specifications	Osburn 3500 Wood Stove
Heat Area	1000-2700 sq. ft.
Overall Dimensions	34-3/4"H x 28-7/8"W x 33-1/2"D
Firebox Volume	3.5 Cubic Feet
Max Log Length	22"
Heat Output	110,000 BTU
Emissions	1.32 g/hr
Efficiency	77%
Burn Time	10 hr
Flue Pipe Diameter	6"
Minimum Chimney Height	15'
Warranty	Limited Lifetime
